"Danfoss - Suction Line Drier 164S 1/2" ODS"
Item Number:
023Z1009
| Max Operating Pressure : | 35.0 Bar |
|---|---|
| Product Group : | Driers - Danfoss |
| Refrigerant : | R22/R407C, R23, R32, R125, R134a, R290, R404A, R407A, R407F, R410A, R422B, R422D, R438A, R444B, R448A, R449A, R449B, R450A, R452A, R452B, R454B, R455A, R507A, R513A, R600, R1234yf, R1234ze(E) |
General Information
| Activated Alumina / Molec. Sieve. : | 70/30 % |
|---|---|
| Approval : | UL |
| Product Group : | Driers - Danfoss |
| Specification Key : | DAS 164SVV |
| Type : | DAS 164SVV |
Additional Info
| Family : | DAS |
|---|
Capacity
| Acid Capacity : | 8.70 g |
|---|---|
| Capacity : | R134a: 6.0 kW, R404A: 8.5 kW, R407C: 10.5 kW, R410A: 10.5 kW, R507: 8.5 kW |
Connections
| Connection Type : | Solder, ODF |
|---|---|
| Inlet Connection Size : | 1/2 in |
| Inlet Type : | Solder, ODF |
| Outlet Connection Size : | 1/2 in |
| Outlet Type : | Solder, ODF |
Driers
| Core : | Solid core |
|---|---|
| Core Size : | 16 cu.in. |
| Flow Capacity Conditions (ARI 730-05) : | Delta p=0.21bar, tevap=4°C |
| Flow Capacity kW : | R134a: 6.0, R404A: 8.5, R407C: 10.5, R410A: 10.5, R507: 8.5 |
| Shell Volume : | 0.35 L |
| Solid Core Surface : | 28.34 in², 183 cm² |
| Solid Core Volume : | 7.84 in³, 128 cm³ |
Logistical Information
| Commodity Code : | 84213985 |
|---|---|
| Country Of Origin : | MEX |
| EAN : | 5702428160445 |
| Gross Weight : | 0.946 kg |
Material
| Body Material : | Steel |
|---|---|
| Connection Material : | Copper |
Measurements
| Net Weight : | 0.84 kg |
|---|---|
| Volume : | 0.226 L |
| Weight : | 0.84 kg |
Pressure
| Max Operating Pressure : | 35.0 Bar |
|---|
Refrigerant
| Refrigerant : | R22/R407C, R23, R32, R125, R134a, R290, R404A, R407A, R407F, R410A, R422B, R422D, R438A, R444B, R448A, R449A, R449B, R450A, R452A, R452B, R454B, R455A, R507A, R513A, R600, R1234yf, R1234ze(E) |
|---|
Temperature
| Max Temperature : | 70 °C |
|---|---|
| Min Temperature : | -40 °C |
| Temperature Range : | -40-70 °C |
Valves
| Flow Direction Indicator : | Label printed 1-way arrow |
|---|---|
| Fluid Group : | 2 |
Product information
Hermetic burn-out filter driers type DAS are used in the suction line to clean up refrigeration and air conditioning systems after a compressor motor burn-out. The solid core, which is composed of 70% activated alumina and 30% Molecular Sieve, adsorbs harmful acids as well as moisture.
Available with flare and solder (pure copper) connections.
