Description
CVP Pilot valve 25 to 52 Bar
Danfoss CVP-H Constant Pressure Pilot Valve 25 to 52 Bar
Product number:
027B0922
| Product Group : | Flow Controls - Other |
|---|
General
| Product Group : | Flow Controls - Other |
|---|
Additional Info
| Family : | ICS + CVP |
|---|
General Information
| Parts Included : | Gasket | Type : | CVP-H |
|---|
Kv Values
| Kv Value : | 0.400 m³/h |
|---|
Logistical Information
| Commodity Code : | 84814010 | Country Of Origin : | POL |
|---|---|---|---|
| EAN : | 5702428557641 | Gross Weight : | 1.65 kg |
| Packaging Height : | 67 mm | Packaging Length : | 255 mm |
| Packaging Width : | 135 mm |
Material
| Surface Coating : | Zn (TLP) |
|---|
Measurements
| Net Weight : | 1.46 kg | Weight : | 1.46 kg |
|---|
Pressure
| Max Operating Pressure : | 52.0 Bar | Pressure Range : | 25.00-52.00 Bar |
|---|
Refrigerant
| Refrigerant : | R22, R32, R125, R134a, R152a, R227ea, R236fa, R245fa, R290, R401A, R402A, R404A, R407A, R407B, R407C, R407F, R407H, R409A, R410A, R413A, R417A, R421A, R422A, R422B, R422D, R438A, R442A, R444B, R447A, R447B, R448A, R449A, R449B, R450A, R452A, R452B, R454A, R454B, R454C, R455A, R463A, R502, R507A, R512A, R513A, R513B, R515A, R515B, R516A, R717, R744, R1233zd(E), R1234yf, R1234ze(E) |
|---|
Standards
| Approval : | EAC, UL |
|---|
Temperature
| Max Temperature : | 120 °C | Min Temperature : | -60 °C |
|---|---|---|---|
| Temperature Range : | -60-120 °C |
Valves
| CV Value : | 0.460 gal/min | Fluid Group : | 1 |
|---|---|---|---|
| Valve Version : | High pressure |
| File name | Document Type | Extension | Size |
|---|---|---|---|
| pilot-valve-type-cvp-cvpp-cvc-cve-evm-and-cvh-ast-ai248786497190en-000701.pdf | Technical Literature | 3.63 MB | |
| manufacturer-s-declaration-danfoss-md-033f1196-01-ast-id410840939200-0201.pdf | Conformity Declaration | 301.63 KB | |
| pilot-valve-type-cvp-cvpp-cvc-cve-evm-and-cvh-ast-ai248786497190en-000801.pdf | Technical Literature | 3.63 MB | |
| manufacturer-s-declaration-danfoss-md-033f0686-ao-ast-id365946903774-0801.pdf | Conformity Declaration | 488.98 KB | |
| brochure-ir-pilot-valves-en-ast-ad208186421597en-000101.pdf | Brochures | 738.27 KB | |
| pilot-valves-cvp-cvpp-cvc-cve-and-evm-ast-an227286436624en-000301.pdf | Installation Manual | 832.05 KB |
