CVH Valve Body (13mm)
Item Number:
027F1090
| Max Operating Pressure : | 52.0 Bar |
|---|---|
| Product Group : | Industrial Controls - Check Valves |
| Refrigerant : | R, R22, R23, R32, R113, R114, R125, R134a, R152a, R170, R227ea, R236fa, R245fa, R290, R401A, R402A, R402B, R404A, R407A, R407B, R407C, R407F, R407H, R408A, R409A, R410A, R413A, R417A, R421A, R422A, R422B, R422D, R427A, R438A, R1150, R1233zd(E), R1234yf, R1234ze(E), R1270, R1336mzz(Z) |
General Information
| Approval : | EAC, LLC CDC TYSK, UL |
|---|---|
| Product Group : | Industrial Controls - Check Valves |
| Type : | CVH |
| Used For : | CVC; CVH; CVK; CVM; CVMH; CVMM; CVMO; CVMP; CVMT; CVP; CVPM; CVPP; CVQ; CVT; EVM |
Additional Info
| Family : | CVH |
|---|
Connections
| Connection Size : | 1/2 in, 15 mm |
|---|---|
| Connection Type : | Weld |
Logistical Information
| Commodity Code : | 84819000 |
|---|---|
| Country Of Origin : | POL |
| EAN : | 5702422186724 |
| Gross Weight : | 0.34 kg |
Material
| Body Material : | Steel |
|---|---|
| Connection Material : | Steel |
Measurements
| Weight : | 0.32 kg |
|---|
Pressure
| Max Operating Pressure : | 52.0 Bar |
|---|
Refrigerant
| Refrigerant : | R, R22, R23, R32, R113, R114, R125, R134a, R152a, R170, R227ea, R236fa, R245fa, R290, R401A, R402A, R402B, R404A, R407A, R407B, R407C, R407F, R407H, R408A, R409A, R410A, R413A, R417A, R421A, R422A, R422B, R422D, R427A, R438A, R1150, R1233zd(E), R1234yf, R1234ze(E), R1270, R1336mzz(Z) |
|---|
Temperature
| Temperature Range : | -50-120 °C |
|---|
Valves
| Flow Direction Indicator : | Embossed 1-way arrow |
|---|---|
| Fluid Group : | 1 |
Product information
CVH 15
