Description
Danfoss ICM 100 Complete Valve
Product number:
027H7131
| Product Group : | Industrial Controls - Pressure Regulators |
|---|
General
| Product Group : | Industrial Controls - Pressure Regulators |
|---|
Compatibility
| Lubricants Compatibility : | Oilfree applications |
|---|
Compressor
| PED Category : | III |
|---|
Connections
| Connection Standard : | ASME B 36.10M SCHEDULE 40 | Inlet Type : | Butt weld |
|---|---|---|---|
| Outlet Type : | Butt weld |
General Information
| Equipment : | Cap | Type : | ICM 100 |
|---|
Kv Values
| Kv Value : | 142 m³/h |
|---|
Logistical Information
| Commodity Code : | 84818073 | Country Of Origin : | CHN |
|---|---|---|---|
| EAN : | 5702428229739 | Gross Weight : | 56.4 kg |
| Packaging Height : | 450 mm | Packaging Length : | 570 mm |
| Packaging Width : | 400 mm |
Material
| Body Material : | Steel | Connection Material : | Steel |
|---|---|---|---|
| Surface Coating : | Zn (TLP) |
Pressure
| Max Operating Pressure : | 52.0 Bar |
|---|
Refrigerant
| Oil Free Refrigerants : | R134a, R1234ze(E) | Refrigerant : | R22, R32, R125, R134a, R227ea, R236fa, R245fa, R401A, R402A, R404A, R407A, R407B, R407C, R407F, R407H, R409A, R410A, R417A, R421A, R422A, R422B, R422D, R438A, R442A, R444B, R447A, R447B, R448A, R449A, R449B, R450A, R452A, R452B, R454A, R454B, R454C, R455A, R463A, R502, R507A, R513A, R513B, R515A, R515B, R516A, R717, R744, R1234yf, R1234ze(E) |
|---|
Standards
| Approval : | EAC, LLC CDC TYSK, TÜV, UL |
|---|
Valves
| Actuator System : | ICAD motor, magnet coupling | CV Value : | 164.72 gal/min |
|---|---|---|---|
| Direction : | Straightway | Flow Direction Indicator : | Embossed 1-way arrow |
| Fluid Group : | 1 | MOPD : | 20 Bar |
| Open/Close Time : | 25 s | Valve Operation : | Motor operated |
| Valve Version : | Standard version |
