"AKV 10P3 Valve ODF-ODF 3/8-1/2inch MU.18"
Item Number:
068F5213
| Max Operating Pressure : | 90 Bar |
|---|---|
| Product Group : | Expansion Valves - Danfoss |
| Refrigerant : | R22, R23, R32, R134a, R290, R404A, R407A, R407C, R407F, R410A, R422D, R438A, R448A, R449A, R450A, R452A, R452B, R455A, R507A, R513A, R600a, R744, R1233zd, R1234yf, R1234ze, R1270 |
General Information
| Model Number : | 068F5213 |
|---|---|
| Product Group : | Expansion Valves - Danfoss |
Additional Info
| Family : | AKV |
|---|
Connections
| Connection Type : | Solder, ODF |
|---|---|
| Inlet Connection Size : | 3/8 in |
| Outlet Connection Size : | 1/2 in |
Kv Values
| Kv Value : | 0.024 m³/h |
|---|
Logistical Information
| Commodity Code : | 84818059 |
|---|---|
| Country Of Origin : | POL |
| EAN : | 5702428669979 |
| Gross Weight : | 0.346 kg |
Measurements
| Net Weight : | 0.3 kg |
|---|---|
| Weight : | 0.300 kg |
Pressure
| Max Operating Pressure : | 90 Bar |
|---|
Refrigerant
| Refrigerant : | R22, R23, R32, R134a, R290, R404A, R407A, R407C, R407F, R410A, R422D, R438A, R448A, R449A, R450A, R452A, R452B, R455A, R507A, R513A, R600a, R744, R1233zd, R1234yf, R1234ze, R1270 |
|---|
Temperature
| Medium Temperature Range : | -50-60 °C |
|---|
Valves
| Coil : | No |
|---|---|
| MOPD : | 35 Bar |
| Orifice Size : | 0.8 mm |
Product information
AKV 10P and AKV10PS are electric operated expansion valves designed for refrigeration plants. The AKV 10P and AKV 10PS valves are normally controlled by a controller from Danfoss range of ADAP- KOOL® controllers, that ensures a precise liquid injection into evaporators.
