Description
AKS 4100 Level Sensor Cable 5m w HMI
AKS 4100 Level Sensor Cable 5m w HMI
Product number:
084H4501
| Product Group : | Electronic Cont - Danfoss |
|---|
General
| Product Group : | Electronic Cont - Danfoss |
|---|
Additional Info
| Family : | AKS 4100 |
|---|
Cable
| Insertion Length : | 197.00 in, 5000 mm |
|---|
Connections
| Connection Size : | 1 in | Connection Type : | G |
|---|
Electrical
| IP Class : | IP67 | Max Load Resistance : | 500 Ohm |
|---|---|---|---|
| Power Consumption : | 0.7 W |
Inputs/Outputs
| Output Signal Range : | 4-20 mA |
|---|
Logistical Information
| Commodity Code : | 90261029 | Country Of Origin : | FRA |
|---|---|---|---|
| EAN : | 5702428414906 | Gross Weight : | 3.682 kg |
Measurements
| Weight : | 2.77 kg |
|---|
Pressure
| Max Operating Pressure : | 100.0 Bar |
|---|
Refrigerant
| Refrigerant : | R22, R134a, R401A, R402A, R404A, R407A, R407B, R407C, R407F, R409A, R410A, R421A, R502, R507A, R717 |
|---|
Standards
| Approval : | CE, EAC, GOST, LLC CDC TYSK, UKCA |
|---|
Temperature
| Ambient Temperature Range : | -40-80 °C | Temperature Range : | -60-100 °C |
|---|
Valves
| Design : | Cable version |
|---|
| File name | Document Type | Extension | Size |
|---|---|---|---|
| data-sheet-liquid-level-sensor-type-aks-4100-and-aks-4100u-ast-ai243386442914en-001201.pdf | Technical Literature | 2.74 MB | |
| manufacturer-s-declaration-danfoss-md-033f0695-aa-ast-id365946929793-0101.pdf | Conformity Declaration | 203.04 KB | |
| installation-guide-liquid-level-sensor-aks-41004100u-coaxial-d14-ast-an23828644201102-000601.pdf | Installation Manual | 17.24 MB | |
| manufacturer-s-declaration-danfoss-md-033f0686-ao-ast-id365946903774-0801.pdf | Conformity Declaration | 488.98 KB | |
| brochure-a-whole-new-level-of-flexibility-and-accuracy-the-aks-4100-liquid-level-sensor-en-ast-ad154586417355en-000301.pdf | Brochures | 601.5 KB |
Spare Part
Product Number: 084H4542
Manufacturer Code: 084H4542
Product Number: 027F1010
Manufacturer Code: 027F1010
Product Number: 084H4548
Manufacturer Code: 084H4548
