Description
BD35F
Danfoss BD35F Recip Compressor R134a 12-24Vdc L/M/HBP
Product number:
195B0722
| Application : | HBP;LBP;MBP |
|---|---|
| Oil Type : | POE |
| Product Group : | Comp Herm - Danfoss |
General
| Product Group : | Comp Herm - Danfoss |
|---|
Application
| Application : | HBP;LBP;MBP |
|---|
Capacity
| Capacity Control : | Fixed speed |
|---|
Compressor
| Free Gas Volume : | 870 cm³ | Power Supply Compressor : | 110-220/1/60 V/Ph/Hz |
|---|---|---|---|
| Swept Volume : | 2.00 cm³ | Technique : | Reciprocating |
Connections
| Discharge Connection Height : | 38 mm | Suction Connection Height : | 81 mm |
|---|
General Information
| Colour : | Black | Model Number : | BD35F |
|---|---|---|---|
| Type : | BD |
Logistical Information
| Commodity Code : | 84143020 | Country Of Origin : | CHN |
|---|---|---|---|
| EAN : | 5702424662158 | Gross Weight : | 5.086 kg |
Material
| Discharge Connection Material : | Copper-plated steel | Suction Connection Material : | Copper-plated steel |
|---|
Measurements
| Height : | 96 mm | Length : | 178 mm |
|---|---|---|---|
| Weight : | 5.05 kg | Width : | 100 mm |
Motor
| Motor Type : | DC/PM |
|---|
Oil
| Oil Type : | POE |
|---|
Refrigerant
| Max Refrigerant Charge : | 0.30 kg | Refrigerant : | R134a |
|---|
| File name | Document Type | Extension | Size |
|---|---|---|---|
| service-guide-fitters-notes-chapter-8-compressors-ast-ax268748862633en-000301.pdf | Technical Literature | 10.35 MB |
