Description
Fasco Fan Motor Thread Shaft J090R05S
Product number:
F3102
| Product Group : | Motors - Open Frame |
|---|
General
| Product Group : | Motors - Open Frame |
|---|
Cable
| Cable Length : | 905 mm |
|---|
Electrical
| Current : | 0.45 A | Power Supply : | 240/1/50 V/Ph/Hz |
|---|
Fan
| Fan Speed : | 2600 r/min | Shaft Diameter : | 4 mm |
|---|---|---|---|
| Shaft Length : | 39.7 mm |
General Information
| Number Of Poles : | 4 |
|---|
Measurements
| Height : | 78.6 mm | Length : | 63.5 mm |
|---|---|---|---|
| Width : | 58.6 mm |
Temperature
| Operating Temperature Range : | -30 °C to 70 °C |
|---|
| File name | Document Type | Extension | Size |
|---|---|---|---|
| j09bm-ast-1891133.pdf | Brochures | 57.33 KB |
