MHI FDUA Series Ducted Set, 10.0kW, Single Phase

Product number: FDUA100AVNAWVH
PLEASE LOGIN TO SEE PRICES
Cooling Capacity : 10.0 kW
EER : 3.9
Heating Capacity : 11.2 kW
Indoor/ Outdoor/ Other : Indoor
Product Group : Ducted Systems - MHI
Refrigerant : R32
Description

The FDUA series of ducted systems is a quiet and discreet solution for multiple rooms. Coming in a range of
capacities ranging from 10kW up to 23.5kW and incorporating a range of convenient features and functions, the FDUA is the perfect heating and cooling solution for any sized Aussie home.

INCREASED ENERGY EFFICIENCY

With an improved heat exchanger in the outdoor unit, boosting refrigerant distribution throughout the system, coupled with our highly efficient DC fan motor and R32 refrigerant, the FDUA series boasts industry-leading energy efficiencies, which means reduced running costs for your home.

SPLITTABLE INDOOR UNIT

The splittable design of the 14 and 16 kW units, allows the indoor unit to be separated into two components for easier handling during installation.

QUIET OPERATION

Thanks to our highly efficient DC fan motor, the FDUA series boasts quiet operation levels. Combined with the unit's Silent Mode, the FDUA series ensures no interruptions to room acoustics and a good night's sleep for you and your family.

WIDER OPERATING RANGE

With a wider operating range, the FDUA series can operate in cooling mode in temperatures up to 50 degrees C** making it suitable for the tough Aussie conditions.

Product Group : Ducted Systems - MHI
Indoor/ Outdoor/ Other : Indoor Indoor Units Connectable (Quantity) : 1
Single Split / Multi Split : Single Split
Cooling Capacity : 10.0 kW Cooling Capacity (Min/Rated/Max) : 4.0 - 10.0 - 11.2 kW
Max Current : 26 A Power Consumption Cooling : 3.05 kW
Power Consumption Heating : 2.87 kW Power Supply : 240/1/50 V/Ph/Hz
COP : 3.28 EER : 3.9
Condensate Water Pump Provided : Yes Remote Control : Yes
Heating Capacity : 11.2 kW Heating Capacity (Min/Rated/Max) : 4.0 - 11.2 - 12.5 kW
Depth : 370 mm Height : 845 mm
Net Weight : 52 kg Weight : 77 kg
Width : 970 mm
Max Height Difference : 50 m Max Piping Length : 50 m
Refrigerant : R32 Refrigerant Charge : 3.3 kg
Refrigerant Pipe Size : 3/8 - 5/8 in Refrigerant precharged up to : 30 m
Sound Pressure Level : 55 dB(A)
Temperature Range Cooling : -15 - 50 °C Temperature Range Heating : -20 - 20 °C
Wire Diameter Interconnection Cable : 3C + E
