Description
Need more performance? Designed for larger units, the Maxi Orange pump gives you the extra power when you need it.
Aspen Maxi Orange
Product number:
FP2210
| Product Group : | Condensate Pumps |
|---|
General
| Product Group : | Condensate Pumps |
|---|
Condensate Pumps
| Flow Rate at 0 m : | 35 L/h | Max Discharge Head : | 15 m |
|---|---|---|---|
| Max Flow Rate : | 35 L/h | Max Suction Head : | 2 m |
Electrical
| Current : | 0.11 A | IP Class : | IP21 |
|---|---|---|---|
| Power Supply : | 230/1/50-60 V/Ph/Hz |
General Information
| Model Number : | FP2210 | Type : | Condensate water pump |
|---|
Logistical Information
| Commodity Code : | 84138100 | Country Of Origin : | CHN |
|---|
Measurements
| Depth : | 122 mm | Height : | 66 mm |
|---|---|---|---|
| Length : | 122 mm | Width : | 44 mm |
Pressure
| Water Flow Pressure : | 35 L/h |
|---|
Sound Power/Pressure
| Sound Pressure Level : | 35 dB(A) |
|---|
Switch
| Safety Switch : | max. 3 |
|---|
Temperature
| Max Condensate Temperature : | 40 °C |
|---|
| File name | Document Type | Extension | Size |
|---|---|---|---|
| fp2210-silent-mini-orange-ast-332567.pdf | Technical Literature | 559.88 KB | |
| mini-maxi-orange-manual-ast-332560.pdf | Installation Manual | 935.98 KB |
