Maneurop Reciprocating Compressor MTZ100-4VI

Product number: MTZ100-4VI
PLEASE LOGIN TO SEE PRICES
Application : H/MBP/AC
Nominal HP : 8.1/3
Oil Type : 175PZ
Power Supply : 440/3/50-60 V/Ph/Hz
Product Group : Comp Herm - Maneurop
Description
MTZ100-4
Product Group : Comp Herm - Maneurop
Family : MTZ
Capacity Control : No
Capacity HBP -5°C : 16460 kW Capacity HBP -5°C R448A : 16460 W
Power Supply Compressor : 400/3/50 460/3/60 V/Ph/Hz Swept Volume : 171.26 cm³
Technique : Reciprocating
Connection Type : Valve/Rotolock Discharge Connection Height : 125 mm
Discharge Connection Pipe Size : 3/4 in Discharge Connection Size : 1 1/4 in
Discharge Line Connection : 1 1/4 in Suction Connection Height : 233 mm
Suction Connection Pipe Size : 1 1/8 in Suction Connection Size : 1 3/4 in
Frequency : 50/60 Hz IP Class : IP54
LRA : 90 A MCC : 22 A
Power Supply : 440/3/50-60 V/Ph/Hz RLA : 15.7 A
Voltage : 380-400/3/50 V/Ph/Hz
Application : H/MBP/AC Colour : Blue
Cooling Type : Suction Model Number : MTZ100HS4AVE
Number Of Cylinders : 4 Type : MTZ
Commodity Code : 84143081 Country Of Origin : FRA
EAN : 5702428888301 Gross Weight : 66.75 kg
Diameter : 352 mm Height : 519 mm
Length : 352 mm Weight : 63 kg
Width : 352 mm
Motor Protector : Internal Motor Type : DOL
Oil Charge : 3900 cm³ Oil Equalization : 3/8'' flare SAE
Oil Type : 175PZ
Nominal HP : 8.1/3
R404A Nominal Capacity -5°C : 10390 W
Max Refrigerant Charge : 10.00 kg Refrigerant : R134a, R404A, R407A, R407C, R407F, R448A, R449A, R452A, R507A, R513A
Expansion Device : V
File name Document Type Extension Size
safety-data-sheet-polyolester-oil-175pz-english-13-04-2022-ast-bh261646311103en-000202.pdf Safety Data Sheet pdf 605.9 KB
installation-guide-danfoss-reciprocating-compressors-mt-mtz-ntz-vtz-ast-an23018649735402-000601.pdf Installation Manual pdf 4.6 MB
electrical-safety-certificate-zw07024-15003d-ast-id365929978114-0101.pdf Conformity Declaration pdf 1.48 MB
electrical-safety-certificate-xw070043-18001a-ast-id365929969107-0101.pdf Conformity Declaration pdf 2.46 MB
installation-guide-instructions-notice-to-assemble-a-reciprocating-tandem-4cyl-ast-an25018649747201-000101.pdf Installation Manual pdf 247.77 KB
brochure-compressors-watch-out-for-counterfeits-to-protect-your-image-en-ast-ad170086418808en-020601.pdf Brochures pdf 3.91 MB
brochure-compressors-watch-out-for-counterfeits-to-protect-your-image-en-ast-ad170086418808en-010501.pdf Brochures pdf 3.91 MB
pressure-safety-certificate-lrqa-0038-uk-per-mad-20040036-a-ast-id423247697665-0101.pdf Conformity Declaration pdf 384.92 KB
eu-uk-declaration-danfoss-eu-uk-8555013-ae-ast-id375130414995-0401.pdf Conformity Declaration pdf 261.28 KB
mechanical-safety-certificate-ul-sa6873-ast-id366040907092-0201.pdf Conformity Declaration pdf 218.64 KB
manufacturer-s-declaration-danfoss-md-8555030-ac-ast-id365946865744-0401.pdf Conformity Declaration pdf 671.76 KB
pressure-safety-certificate-nsw-pv-6-218318-17-ast-id366030047879-0101.pdf Conformity Declaration pdf 379.28 KB
maneurop-mt-mtz-application-guidlines-ast-599000.pdf Technical Literature pdf 3.84 MB
manufacturer-s-declaration-danfoss-md-8555014-ab-ast-id365946860740-0301.pdf Conformity Declaration pdf 915.78 KB
manufacturer-s-declaration-danfoss-md-8555016-ab-ast-id365946861741-0301.pdf Conformity Declaration pdf 1.16 MB
manufacturer-s-declaration-danfoss-md-8555038-aa-ast-id381948536328-0101.pdf Conformity Declaration pdf 393.53 KB
manufacturer-s-declaration-danfoss-md-8555032-d-ast-id365946790688-0101.pdf Conformity Declaration pdf 449.83 KB

Spare Part

Maneurop Crank Heater MT/MTZ
Product Number: 120Z0459
Manufacturer Code: 120Z0459
