Embraco Compressor NEK2150GK Embraco Compressor R404a220-240v50hz

Product number: NEK2150GK
PLEASE LOGIN TO SEE PRICES
Application : LBP
Displacement : 12.12 cm³
Nominal HP : 0.75 HP
Oil Type : POE 22
Power Supply : 220-240/1/50 V/Ph/Hz
Product Group : Comp Herm - Embraco
VSD Capable : No
Description

The NE family was developed for low and medium temp and can go up to 1HP. The line is ideal for ice makers, slushy machines, and reach-in freezers and can also be considered and applied in medical and scientific refrigerators. The medium size, highly efficient and sturdy NE compressor can be found in the high-starting torque version and is available for R134a, R404A and R290 and more.

  • Reliable for challenging applications

  • Available in 100, 115, and 208-230 V

  • 50/60 Hz Input Frequency

  • Applications: LBP, MBP, M/HBP

  • Refrigerant Compatibility: R134a; R513A; R290; R404A; R448A; R449A; R452A

Product Group : Comp Herm - Embraco
Family : NE
Displacement : 12.12 cm³ Power Supply Compressor : 220-240/1/50 V/Ph/Hz
Connection Type : Tube Discharge Connection Size : 1/4 in
Discharge Line Connection : 6.1 mm Discharge Line Connection Type : Tube
Suction Connection Size : 5/16 in Suction Line Connection : 8.2 mm
Suction Line Connection Type : Tube
LRA : 19.5 A Power Supply : 220-240/1/50 V/Ph/Hz
RLA : 3.2 A Voltage : 220-240/1/50 V
Application : LBP Cylinder Volume : 12.12 cm³
Model Number : NEK2150GK VSD Capable : No
Height : 206 mm Length : 242 mm
Net Weight : 11.6 kg Weight : 11.6 kg
Width : 178 mm
Motor Type : CSIR
Mounting Details : 170x70
Oil Charge : 0.35 dm³ Oil Type : POE 22
Nominal HP : 0.75 HP
R404A Capacity -20°C : 520 W R404A Cooling Capacity Rated -35°C : 0.29 kW
R404A Power Input -35°C : 0.35 kW
R452A Cooling Capacity Rated -35°C : 0.27 kW R452A Power Input -35°C : 0.33 kW
Refrigerant : R404A, R452A
Expansion Device : C-V
File name Document Type Extension Size
nek2150gk-ast-351539.pdf Technical Literature pdf 115.94 KB
