Embraco Compressor NJ9238GK R404A Compressor 220-240v 50Hz

Product number: NJ9238GK-STUB

PLEASE LOGIN TO SEE PRICES

Further products

Application :	HBP
Displacement :	32.7 cm³
Nominal HP :	1.5 HP
Oil Type :	POE 22
Power Supply :	220-240/1/50 V/Ph/Hz
Product Group :	Comp Herm - Embraco
VSD Capable :	No

Description

Embraco’s NJ models, together with the NT models, are in the large frame category and are popular among commercial OEMs. NJs are used in reach-in freezers, cold rooms, medical chillers and grab-n-go merchandisers. They are very reliable for high cooling demands in ultra-low, low and medium temp applications while keeping low noise and vibration levels.

Reliable for challenging applications
Available in 115 V, 208-230 V, and 3PH
50/60 Hz Input Frequency

1-2 HP
Refrigerant Compatibility: R134a; R513A; R290; R407C; R22; R404A; R448A; R449A; R452A
Applications: LBP, MBP, M/HBP

General

Product Group :	Comp Herm - Embraco

Additional Info

Family :	NJ

Compressor

Displacement :	32.7 cm³	Power Supply Compressor :	230/1/50 V/Ph/Hz

Connections

Connection Type :	Tube	Discharge Connection Size :	5/16 in
Discharge Line Connection :	8 mm	Discharge Line Connection Type :	Tube
Suction Connection Size :	1/2 in	Suction Line Connection :	12.8 mm
Suction Line Connection Type :	Tube

Electrical

LRA :	43 A	Power Supply :	220-240/1/50 V/Ph/Hz
RLA :	7.6 A	Voltage :	220-240/1/50 V

General Information

Application :	HBP	Cylinder Volume :	32.7 cm³
Model Number :	NJ9238GK	VSD Capable :	No

Measurements

Height :	277 mm	Length :	224 mm
Net Weight :	22.1 kg	Weight :	22.1 kg
Width :	180 mm

Motor

Motor Type :	CSR

Mounting

Mounting Details :	203x122

Oil

Oil Charge :	0.75 dm³	Oil Type :	POE 22

Performance

Nominal HP :	1.5 HP

R404A Performances

R404A Capacity -5°C :	2970 W	R404A Cooling Capacity Rated -10°C :	2.26 kW
R404A Power Input -10°C :	2.04 kW

R452A Performances

R452A Cooling Capacity Rated -10°C :	2.19 kW	R452A Power Input -10°C :	2.03 kW

Refrigerant

Refrigerant :	R404A, R452A

Valves

Expansion Device :	C-V

File name	Document Type	Extension	Size
nj9238gk-ast-351567.pdf	Technical Literature	pdf	115.79 KB
