Description
Med Temp Unit Cooler PM105 EVD ICE with Ultra Cap
Product number:
W5505-EVD
| Fin Spacing : | 3 mm |
|---|---|
| Product Group : | Evap - Patton MT |
| R134a Capacity @ -4SST/6KTD : | 9690 W |
| Temperature Application : | Medium Temp |
General
| Product Group : | Evap - Patton MT |
|---|
Air Volume/Air Flow
| Air Throw : | 15 m | Air Volume : | 8352 m³/h |
|---|
Coils
| Coil : | Fin and Tube |
|---|
Connections
| Drain Connection Size : | 20 mm | Liquid Line Connection : | 5/8 in |
|---|---|---|---|
| Suction Line Connection : | 7/8 in |
Drain
| Drain Location : | Right |
|---|
Electrical
| Electric Defrost : | Yes | Electrical Connection Location : | Right |
|---|
Evaporator
| Fin Spacing : | 3 mm |
|---|
Fan
| Fan Size : | 350 mm | Number Of Fans : | 3 |
|---|
Measurements
| Depth : | 431 mm | Height : | 479 mm |
|---|---|---|---|
| Length : | 1813 mm | Weight : | 50 kg |
R134A Performances
| R134a Capacity @ -4SST/6KTD : | 9690 W |
|---|
R404A Performances
| R404A Capacity @ -4SST/6KTD : | 10650 W |
|---|
R448A Performances
| R448A Capacity @ -4SST/6KTD : | 10860 W |
|---|
Temperature
| Temperature Application : | Medium Temp |
|---|
| File name | Document Type | Extension | Size |
|---|---|---|---|
| patton-p-series-en-ast-609007.pdf | Technical Literature | 1.04 MB |
