Description
Copeland Scroll Compressor ZF24K4E-TWD-951-C
Product number:
ZF24K4E-TWD-951-C
| Displacement : | 126 m³/h |
|---|---|
| Nominal HP : | 7.5 HP |
| Oil Type : | POE |
| Product Group : | Comp Scroll - Copeland |
| VSD Capable : | Yes |
General
| Product Group : | Comp Scroll - Copeland |
|---|
Capacity
| Capacity Control : | No |
|---|
Compressor
| Displacement : | 126 m³/h |
|---|
Connections
| Discharge Line Connection : | 22.22 mm | Suction Line Connection : | 35 mm |
|---|
Electrical
| MOC : | 12.2 A | Voltage : | 380-420/3/50 V/Ph/Hz |
|---|
General Information
| VSD Capable : | Yes |
|---|
Measurements
| Height : | 525 mm | Weight : | 100 kg |
|---|
Motor
| Motor Protector : | Internal | Motor Type : | DOL |
|---|
Oil
| Oil Charge : | 4100 cc | Oil Type : | POE |
|---|
Performance
| Nominal HP : | 7.5 HP |
|---|
R404A Performances
| R404A Nominal Capacity -25°C : | 5800 W |
|---|
| File name | Document Type | Extension | Size |
|---|---|---|---|
| zf24k4etwd-ast-598963.pdf | Technical Literature | 119.62 KB |
