Copeland Scroll Compressor ZP137KCE-TFD-522-C
Product number:
ZP137KCE-TFD-522-C
| Displacement : | 22.1 m³/h |
|---|---|
| Oil Type : | POE |
| Product Group : | Comp Scroll - Copeland |
| VSD Capable : | Yes |
General
| Product Group : | Comp Scroll - Copeland |
|---|
Capacity
| Capacity Control : | No |
|---|
Compressor
| Displacement : | 22.1 m³/h |
|---|
Connections
| Discharge Line Connection : | 22.22 mm | Suction Line Connection : | 35 mm |
|---|
Electrical
| MOC : | 20.7 A | Voltage : | 380-420/3/50 V/Ph/Hz |
|---|
General Information
| VSD Capable : | Yes |
|---|
Measurements
| Height : | 552 mm | Weight : | 118 kg |
|---|
Motor
| Motor Protector : | Internal | Motor Type : | DOL |
|---|
Oil
| Oil Charge : | 3130 cc | Oil Type : | POE |
|---|
R22 Performances
| R22 Nominal Capacity 7.2°C : | 30100 W |
|---|
| File name | Document Type | Extension | Size |
|---|---|---|---|
| zp137kcetfd-ast-598975.pdf | Technical Literature | 60.6 KB |
