Description
Copeland Scroll Compressor ZR40K3ETFD522-C
Product number:
ZR40K3ETFD522-C
| Displacement : | 51.2 m³/h |
|---|---|
| Nominal HP : | 3.3 HP |
| Oil Type : | POE |
| Product Group : | Comp Scroll - Copeland |
| VSD Capable : | Yes |
General
| Product Group : | Comp Scroll - Copeland |
|---|
Capacity
| Capacity Control : | No |
|---|
Compressor
| Displacement : | 51.2 m³/h |
|---|
Connections
| Discharge Line Connection : | 12.7 mm | Suction Line Connection : | 22.22 mm |
|---|
Electrical
| MOC : | 6.4 A | Voltage : | 380-420/3/50 V/Ph/Hz |
|---|
General Information
| VSD Capable : | Yes |
|---|
Measurements
| Height : | 420 mm | Weight : | 32 kg |
|---|
Motor
| Motor Protector : | Internal | Motor Type : | DOL |
|---|
Oil
| Oil Charge : | 1100 cc | Oil Type : | POE |
|---|
Performance
| Nominal HP : | 3.3 HP |
|---|
R22 Performances
| R22 Nominal Capacity 7.2°C : | 9260 W |
|---|
| File name | Document Type | Extension | Size |
|---|---|---|---|
| zr40k3etfd-ast-598982.pdf | Technical Literature | 8.62 KB |
